Windows

Single-hung, Slider and Picture Windows

1-3/8” Nail-Fin for New Construction Openings

Flush-Fin for Replacement Openings
Robust & Modern
The Autograph Series is a flexible, high performing design for multi-family & high-end residential. I tis available with the shortest lead-time in the industry. Available in Eclipse, White, Almond, Clay, or Black with White interior.


- Multiple configurations to include SL, SH, Picture. Shapes include trapezoids, round & arch-top, rounds and octagon
- 3-1/2” frame depth provides strong performance
- An accessory J-Channel can be added to any standard frame window or door
- Multi-chambered frame with weep channels for efficient drainage
- SunShield® Vinyl offers superior weather resistance with no fading
- Interlocking sash for better air & water infiltration resistance
- DP50 high performance baseline design
- Cam-Lock standard but Auto-Locks are available as an option
- Insulated glass is 3/4” OA with Double Strength glass & Argon standard
- 1-1/8” OA for Triple Glazed performance IG glazing is available
- Limited lifetime warranty
Performance Ranges:
Structural
NAFS: UP to LC-PG55
Thermal
U Factor: Down to .18
Acoustical
STC: Up to 32db
